Enviromental & air quality sensor BME680 breakout
SKU: 333035
Bulk order
Get a special price per unit if you order more
[pricing_table]
78 items available
$18.16
78 in stock
24/7 lifetime customer and technical support
2-year Warranty - no questions asked
Comprehensive Documentation
Open-source everything
Product Description
The BME680 is an atmospheric sensor that measures four values: temperature, pressure, humidity and air quality as an IAQ index. Using that data can calculate elevation. It is really simple to use considering that it’s using I2C communication protocol and its dimensions are really small so it can fit anywhere. Everything you need to know about the atmospheric conditions and the quality of the air – you can find out using this sensor (ideal for weather station projects!) This board comes with two easyC connectors, providing easy connection to other products.
Product features
Complimentary technical support
In case you ever get stuck with using this product, you can count on us. We provide free, no-strings-attached technical support with this product. Just reach out to us with your questions, and we'll be there to help you.
easyC
easyC is a system for simple connection of microcontroller boards, sensors and actuators that enables fast prototyping without the possibility of error. The connection between the modules takes place with simple cables. easyC is based on I2C communication. Read more here.
Open-source
Open-source culture is rooted deep inside us, and that’s reflected in our products. This product follows the open-source principle. It was made with the community’s suggestions and needs in mind. With a modular design, it can be modified to your needs and incorporated into your projects. We provide all the design documentation needed free of charge on our Github repository.
Made in EU
Soldered products, designed and manufactured in Croatia, are thoroughly tested and meet the highest EU standards of quality and safety.
Key features
- Voltage: 1.71V - 3.6V
- Pressure measurement range:Â 30kPa - 110kPa
- Pressure measurement error: +-12Pa
- Temperature measurement range: -40C - 85C
- Temperature measurement error: +-1C
- Humidity measurement range: 0% - 100%
- Humidity measurement error: +-3%
- IAQ index measurement range: 0 - 500
- Measuring consumption: max. 849uA
- Consumption in idle state: 0.15uA
- Dimensions: 22 x 22 mm / 0.9 x 0.9 inch
Useful links & tutorials
Arduino library
Product datasheet
CE certificate Customer reviews & ratings
